Tilting Rotary Furnace
Our Tilting Rotary Furnaces represent the pinnacle of rotary melting technology, designed for efficient processing of various metal scrap and secondary raw materials. The rotational motion ensures thorough mixing and optimal heat transfer, while the tilting mechanism allows for safe and controlled pouring.
Request a quote for the Tilting Rotary Furnace
250 kg – 15,000 kg
Capacity
800°C
Max Temp
0°–120°
Tilting Angle
Technical Specifications
- Capacity Range
- 250 kg to 15,000 kg per batch
- Maximum Temperature
- 800°C
- Burner System
- High-velocity oxygen-fuel burners
- Rotation Speed
- Variable, 0–5 RPM
- Tilting Angle
- 0°–120°
- Control System
- Manual or PLC with touchscreen interface
- Energy Options
- Natural gas, LPG, or oil
Applications
Aluminium & alloy recyclingCopper & alloy meltingZinc & lead recoveryPrecious-metal reclamationDross & metal-bearing residue processing
